Ufix Plastic Spacer

Ufix Plastic Spacer

The Ufix Plastic Spacer is a rebar support without locking clamps, designed to provide a stable base for reinforcement bars. Unlike traditional spacers, it does not have clamping arms and simply serves as a seating platform for rebars.

Key Features

• Point load capacity: up to 200 kg
• Universal compatibility: No diameter restrictions for rebars
• Easy placement: Installed before laying the reinforcement mesh
• Ideal for pre-tied rebar meshes in foundations and slabs

Why Use Ufix Spacer?

In some slabs and floors, pre-tied reinforcement meshes are used. Placing conventional spacers underneath these meshes can be difficult and time-consuming. The Ufix Spacer simplifies this process by allowing rebars to be placed directly on top of it.

Installation of Ufix Spacer

1. Place Ufix Spacers on the surface before spreading the rebar mesh.
2. Lay the reinforcement bars or mesh directly on the spacers.
3. Ensure proper spacing to distribute the load evenly.

Consumption Rate

For medium-weight foundations and floors:

• 4 spacers per square meter

For heavy and high-volume slabs:

• 6 to 10 spacers per square meter, depending on load requirements

For beams and girders:

• 3 spacers per meter (typically 2 spacers per row, spaced 60-70 cm apart)

Important Considerations

• Designed for medium-weight structures such as beams, girders, and floors
• If used in heavy structures with dense reinforcement, first calculate the total weight per square meter to determine the required number of spacers
• For high loads (above 200 kg point load) or rebar sizes above 25mm, it is recommended to use Hard Fix Spacers instead
• Not suitable for high-movement zones or large-scale concrete pouring due to the lack of locking clamps
