Plastic Ribbed Pipe

Plastic Ribbed Pipe (PVC Ribbed Pipe)

The plastic ribbed pipe, made of UPVC material, is widely used as an intermediate component between the waterproof mid-bolt and the dual-cone sleeve in concrete formwork. In cases where sealing the area through which the bolt passes in the concrete is not critical, the ribbed pipe can also serve as a simple sleeve for bolt passage.

This plastic pipe is manufactured with a diameter of 25 mm and a wall thickness of 1.8 mm, although the wall thickness can be customized upon request. The pipe is ribbed using a thermal and pressure machine, which increases its grip on the concrete, providing better engagement during use.

Applications of Plastic Ribbed Pipe

1. Intermediate Component for Waterproof Mid-Bolt: The ribbed plastic pipe can be used as an intermediary between the waterproof mid-bolt and the dual-cone sleeve.
2. Sleeve for Bolt Passage: In cases where the sealing of the bolt passage is not of high importance, the ribbed plastic pipe can be used as a simple sleeve to allow the bolt to pass through the formwork.
3. Intermediate Sleeve for Dual-Coned Sleeve: The ribbed pipe can also serve as an intermediary sleeve between the dual-cone and the waterproof mid-bolt.

Consumption of Plastic Ribbed Pipe

• As an Intermediate Component for Waterproof Mid-Bolt: To use the ribbed pipe as an intermediary for a waterproof mid-bolt, subtract 16 cm from the wall thickness to determine the required length of the ribbed pipe.
• As an Intermediate Sleeve for Dual-Coned Sleeve: For this application, subtract 2 cm from the wall thickness to determine the required length of the ribbed pipe.
• As a Sleeve for Bolt Passage: For bolt passage, the ribbed pipe must be cut to the width of the wall.

Important Notes Regarding the Plastic Ribbed Pipe

• Using the ribbed plastic pipe as a sleeve for bolt passage ensures that bolts remain intact, providing more precision, efficiency, and extending the lifespan of the bolts for use in future projects.

Packaging of Plastic Ribbed Pipe

Each standard package typically contains 20 pieces of 3-meter long plastic ribbed pipe.
